Yamaha G22 (2003-2007) (48V) Fleet Lithium Conversion Kit
10-Year Warranty / 5,000+ Cycles
10-Year Warranty / 5,000+ Cycles
Built for the long haul. Every Promise-series battery is backed by a 10-year manufacturer's warranty and rated for 5,000+ cycles at 80% depth of discharge. View full warranty details.
Product Highlights
Product Highlights
Yamaha G22 (2003-2007) (48V) Fleet Lithium Conversion Kit - 51V 168Ahis backordered and will ship as soon as it is back in stock.
Yamaha G22 (2003-2007) (48V) Fleet Lithium Conversion Kit
Upgrade Your Yamaha G22 to Fleet Lithium
Replace the factory lead-acid batteries in your Yamaha G22 with a single, high-performance 51V LiFePO4 pack from Fleet Lithium. Complete conversion kit — battery, charger, bracket, cables, and all hardware included.
Choose Your Capacity
| Capacity | Range | Best For |
|---|---|---|
| 51V 105Ah | Up to 50 mi | Daily driving, golf |
| 51V 168Ah | Up to 75 mi | All-day use |
| 51V 210Ah | Up to 90 mi | Max range, fleet use |
What's Included
- 51V NexGen Fleet Lithium LiFePO4 Battery (selected capacity)
- CH5618 — 58.4V 18A LiFePO4 Smart Charger
- BR2161 — Yamaha G22 Bracket Kit
- AC0219 — AC Power Connector
- CB0917 — Cable Set (35.4")
- Digital State-of-Charge Gauge
- All mounting hardware
Key Specs
- 300A NexGen BMS with 800A peak surge
- Patent-pending fire suppression system
- Built-in cold-weather heater — activates automatically below 32°F (standard, not an add-on)
- Bluetooth monitoring — voltage, temp, cycle count from your phone
- 10-year warranty — designed and assembled in the USA
Fitment Guide
| OEM | Model | Years | Factory Voltage |
|---|---|---|---|
| Yamaha | G22 | 2003–2007 | 48V |
Controller Compatibility
The Yamaha G22 uses a factory 48V controller. The Fleet Lithium 51V pack is fully compatible — no reprogramming or controller changes required.
Will this fit my Yamaha G22?
Yes. The BR2161 bracket kit provides a factory-fit installation. No modifications required.
Does my controller need reprogramming?
No. The factory 48V controller on the G22 accepts the 51V lithium pack without changes.
How long does installation take?
30–60 minutes with basic hand tools.
Does it work in cold weather?
Yes. Built-in heater activates automatically below 32°F — standard on every pack.
*Range estimates are maximums under ideal conditions (flat terrain, single rider, 12–15 mph, 70°F). Actual range varies with terrain, weight, speed, and temperature.
Quick answer: the Yamaha G22 (2003-2007) (48V) Fleet Lithium Conversion Kit from Fleet Lithium has nominal voltage 51.2V, capacity 105 AH, continuous / peak discharge 300A continuous / 800A peak surge, cycle life 5,000+ cycles at 80% Depth of Discharge (DoD), chemistry Lithium Iron Phosphate (LiFePO4), warranty 10 Year Warranty. The complete specification table for this configuration is below.
Electrical & Performance
- Nominal Voltage
- Factory Pack Voltage
- Capacity
- Nominal Energy
- Continuous / Peak Discharge
- Cold Crank Amps
- Charging Voltage
- Charging Current
- Discharge Cutoff Voltage
- Cycle Life
Battery & BMS
- Chemistry
- Battery Technology
- Battery Type
- EV Battery Type
- BMS Features
- 300A Continuous / 800A Peak Surge Discharge, Advanced Battery Management System (BMS), Internal Heating for Cold Temp Charging, Active Cell Balancing for Extended Life Cycle, Built in Fire Extinguisher for Ultimate Safety
- Safety Features
- Thermal Regulation (Heated Cells), Low Voltage Disconnect (LVD), Over Charge / Discharge Protection, Over Current Protection
- Battery Features
- EV Battery Features
- Operating Temperature
- Charging: 32 to 140 ºF (0 to 60 ºC), Discharging: -4 to 149 ºF (-20 to 65 ºC)
Dimensions & Weight
- Dimensions (L x W x H)
Fitment & Compatibility
- Make
- Model
- Model Year
- 2003, 2004, 2005, 2006, 2007
- Model Number
- Motor Controller
Warranty & Compliance
- Warranty
- Certifications
- UL 1642, UL 1973, CE, RoHS, UN38.3, IP67
- Standards
- Condition
- Manufacturer Relationship
Product Details
- Classification
- Colour / Finish
- Vendor
- Fleet Lithium
- Product Type
- Lithium Battery Conversion Kit
- SKU
- YA5542
- Shipping Weight
- 177.0 lb
