BlueMax Marine 12V 200Ah LiFePO4 Deep Cycle Battery (Group 27)
BlueMax Marine 12V 200Ah LiFePO4 Deep Cycle Battery (Group 27)is backordered and will ship as soon as it is back in stock.
Features
Features
8 Year Warranty
8 Year Warranty
Subscribe to our newsletter
Sign up for exclusive offers.
BlueMax Marine 12V 200Ah LiFePO4 Deep Cycle Battery (Group 27)
BlueMax Marine 12V 200Ah LiFePO4 Deep Cycle Battery (Group 27)
High-capacity 12V 200Ah LiFePO4 deep cycle battery from BlueMax Marine. Built for heavy-duty marine, RV, off-grid solar, and trolling motor applications where extended runtime matters most.
Key Specs
- Chemistry: LiFePO4
- Voltage: 12V
- Capacity: 200Ah
- Form Factor: Group 27
- Cycle Life: 5,000+ cycles at 80% DoD
- BMS with overcharge, over-discharge, short circuit, and thermal protection
- Bluetooth monitoring
FAQ
What is this battery best for? High-demand marine trolling, RV house power, off-grid solar storage, and backup power systems requiring extended runtime.
Is this a drop-in replacement for lead-acid? Yes. Group 27 form factor fits standard battery trays. Requires a LiFePO4-compatible charger.
Quick answer: the BlueMax Marine 12V 200Ah LiFePO4 Deep Cycle Battery (Group 27) from Fleet Lithium has nominal voltage 12.8V, capacity 200 AH, continuous / peak discharge 40A continuous / 500A peak surge, cycle life 5,000+ cycles at 80% Depth of Discharge (DoD), cell chemistry Lithium iron phosphate (LiFePO4), warranty 8 Year Warranty. The complete specification table for this configuration is below.
Electrical & Performance
- Nominal Voltage
- Capacity
- Nominal Energy
- Continuous / Peak Discharge
- Cold Crank Amps
- Charging Voltage
- Charging Current
- Discharge Cutoff Voltage
- Cycle Life
Battery & BMS
- Cell Chemistry
- Battery Type
- EV Battery Type
- BMS Features
- Advanced Battery Management System (BMS)
- Safety Features
- Over Charge / Discharge Protection
- Battery Features
- EV Battery Features
- Operating Temperature
- Charging: 0°C to 45°C (32°F to 113°F) , Discharging: -20°C to 60°C (-4°F to 140°F)
Dimensions & Weight
- Dimensions (L x W x H)
- Length
- Width
- Height
Fitment & Compatibility
- Make
- Model
Warranty & Compliance
- Warranty
- Certifications
- UL 1642 , UL 1973 , CE , RoHS , UN38.3 , IP67
- Standards
- Condition
- Manufacturer Relationship
Product Details
- Classification
- Colour / Finish
- Vendor
- Fleet Lithium
- Product Type
- 12 Volt Lithium
- SKU
- BMDC12V200
- Shipping Weight
- 27.0 lb
Pair it right
Make sure this pack matches your motor
Trolling motors pull about one amp per pound of thrust. Enter your motor, hours and throttle to confirm this capacity covers your day on the water.
Size your marine pack
—
Estimate based on ~1A per lb of thrust at 12V and 80% usable depth of discharge. Message us with your rig for an exact recommendation.
100% usable capacity
A 100Ah lead-acid bank gives you 50Ah before it sags. A Fleet Lithium 105Ah pack delivers the full rating, every trip.
Half the weight
Drop 60+ lbs off the transom versus flooded lead-acid and get it back in hull speed and range.
Flat voltage all day
Lithium holds voltage to the end of the charge, so your motor pulls the same thrust on the last hour as the first.
5,000+ cycles, 10-year warranty
Sealed, maintenance-free and IP-rated for the marine environment. No watering, no acid, no off-season top-ups.
