76.8V 105Ah Fleet Lithium Battery — NexGen BMS
Achieve maximum range and constant torque with zero maintenance. 8,064Wh of usable energy for 72V/76.8V vehicles, marine, and off-grid systems. Monitor state of charge, voltage, and cycle count via Bluetooth 5.0. Integrated fire suppression and advanced NexGen BMS.
What This Upgrade Fixes
- Eliminates voltage sag and sluggish performance common in aging lead-acid setups
- Cures range anxiety with consistent, fade-free power down to the last drop of capacity
- Removes hundreds of pounds of dead weight, improving acceleration, handling, and braking
- Ends the hassle of terminal corrosion, acid leaks, and seasonal battery watering
What's Included
1× 76.8V 105Ah Fleet Lithium Battery. Standalone bare battery unit. An 87.6V lithium charger, voltage reducer, custom wiring, and mounting brackets are not included.
Compatibility
Universal 76.8V power unit optimized for high-draw environments. Drops directly into custom 72V or 76.8V electrical systems. Compatible with 72V golf carts, LSVs, UTVs, deep-cycle marine applications, and off-grid solar banks.
Key Specs
- Chemistry: LiFePO4
- Nominal Voltage: 76.8V
- Capacity: 105Ah (8,064 Wh / 8.064 kWh)
- Cell Configuration: 24S1P
- Working Voltage: 64.8V – 87.6V
- Charging Voltage: 87.6V
- BMS Voltage Cutoff: 64.8V
- Recommended Low Voltage Disconnect: 73.5V
- 300A NexGen BMS with 800A peak surge
- Cycle Life: Up to 6,000 cycles at 80% DoD
- Weight: ~148 lbs (67 kg)
- Dimensions: 20.51" × 12.24" × 10.94"
- Enclosure: Cold rolled steel, IP65
- Operating Temp (Discharge): -20°C to 55°C (-4°F to 131°F)
- Operating Temp (Charge): 0°C to 55°C (32°F to 131°F) — heater activates below 32°F
- Communication: Bluetooth, GPS, RS485, UART, CAN
FAQ
Does this battery include a charger? No. You will need a dedicated 87.6V lithium charger.
Will this work in severe cold climates? Yes. The NexGen BMS automatically activates internal heating below 32°F.
How long will this battery actually last? Engineered for over a decade of reliable performance and backed by our 10-year warranty.
Can I integrate this with a sophisticated motor controller? Yes. The integrated BMS provides CANBUS and RS485 ports.
