48V Stackable Wall Mounted Solar Battery System
48V Stackable Wall Mounted Solar Battery System - 100 AHis backordered and will ship as soon as it is back in stock.
48V Stackable Wall Mounted Solar Battery System
Size it right the first time
How much storage do you need?
Pick the loads you want to carry and how long you want them running. We will tell you which capacity to start with and when to stack a second unit.
Storage calculator
—
Estimate based on 90% usable depth of discharge. Send us your load list and we will size the full system with you.
-
Stackable by design
Start with one unit and add more as your loads grow. Same rack, same comms, no re-engineering.
-
100% usable capacity
Lead-acid gives you half its rating. You get the full bank you paid for.
-
Talks to your inverter
RS232 / RS485 / CAN bus, with profiles for Growatt, Victron, Deye, Goodwe and more.
-
8-year warranty
5,000+ cycles at 80% DoD, backed for 8 years and supported from the USA.
48V Stackable Wall-Mounted Solar Battery System
Modular 51.2V LiFePO4 wall-mounted battery system for residential and off-grid solar storage. Stackable design — add capacity as your needs grow.
Choose Your Capacity
| Capacity | Energy | Best For |
|---|---|---|
| 100Ah | 5.12 kWh | Small cabin, backup essentials |
| 200Ah | 10.24 kWh | Full home backup, moderate use |
| 280Ah | 14.34 kWh | Whole-home off-grid, heavy loads |
Key Specs
- Voltage: 51.2V nominal
- BMS: 100A charge/discharge
- Communication: RS232 / RS485 / CAN bus
- Chemistry: LiFePO4 (Lithium Iron Phosphate)
- Mounting: Wall-mounted, stackable
- Compatible inverters: Growatt, Victron, Deye, Goodwe, and others
Applications
Residential solar storage, off-grid cabins, RV/camper backup, emergency home power.
Quick answer: the 48V Stackable Wall Mounted Solar Battery System from Fleet Lithium has nominal voltage 51.2V, capacity 100 AH, continuous / peak discharge 800A (peak), 300A (continuous), cycle life 5,000+ cycles at 80% Depth of Discharge (DoD), cell chemistry Lithium Iron Phosphate (LiFePO4), warranty 8 Year Warranty. The complete specification table for this configuration is below.
Electrical & Performance
- Nominal Voltage
- Factory Pack Voltage
- Capacity
- Nominal Energy
- Continuous / Peak Discharge
- Charging Current
- Cycle Life
Battery & BMS
- Cell Chemistry
- BMS Features
- Advanced Battery Management System (BMS) , Active Cell Balancing for Extended Life Cycle
- Safety Features
- Low Temp Charging Cutoff , Over Charge / Discharge Protection , Over Current Protection , Low Voltage Disconnect (LVD)
- Operating Temperature
- Charging: 32 to 140 ºF (0 to 60 ºC) , Discharging: -4 to 149 ºF (-20 to 65 ºC) , Storage: 50 to 113 ºF (10 to 45 ºC)
Dimensions & Weight
- Length
- Width
- Height
- Weight
- 110.0 lb
Warranty & Compliance
- Warranty
- Certifications & Standards
- UL 1642, UL 1973, CE, RoHS, UN 38.3, IP67
Product Details
- Classification
- Colour / Finish
- Vendor
- Fleet Lithium
- Product Type
- Solar Bundle
- SKU
- FL-51100
